SD6E425MB-HNR-A-PV1-ATC
4MP 25× Anti-corrosion WizSense PTZ Camera
Key Points

High-Quality Imaging with 4MP Resolution

25× Optical Zoom Provide Close Up Views Over Expansive Areas

Smart Dual Light: Expansive Night View with up to 250m IR Distance and 100m Warm Light

Red & Blue Warning Lights and Alarm Sounds for Active Deterrence

Built-in Dual Mic & Speaker: Secure Real-Time Talk

IP67 and IK10 Ratings for Protection Against Harsh Environments

Anti-Corrosion Design (NEMA 4X, C5-H) for Reliable Protection

Sales Enquiry
Datasheet
Specifications
Camera
Lens
Intelligence
Video
Audio
Alarm
Network
Function
PTZ
Certification
Port
Power
Environment
Structure
Camera
Image Sensor 1/2.8″ CMOS
Max. Resolution 2688 (H) × 1520 (V)
Scanning System Progressive
Electronic Shutter Speed 1s–1/30,000s
Min. Illumination 0.005 lux@F1.6 (Color, 30 IRE)
0.0005 lux@F1.6 (B/W, 30 IRE)
0 lux (illuminator on)
S/N Ratio >56 dB
Illumination Distance Up to 100 m (328.08 ft) (Warm light)
Up to 250 m (820.21 ft) (IR)
Illuminator On/Off Control Auto;Manual;Zoomprio
Illuminator Number 6 (Multi-core (IR + warm) light)
Lens
Optical Zoom 25×
Hybrid Zoom 25×
Lens Mount Module
Focal Length 5 mm–125 mm
Max. Aperture F1.6–F3.6
Field of View H: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7°
Iris Control Auto;Manual
Iris Control Type DC-Iris
Close Focus Distance 0.1 m–0.5 m (0.33 ft–1.64 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
100.0 m
( 328.08 ft)
39.5 m
( 129.59 ft)
20.0 m
( 65.62 ft)
10.0 m
( 32.81 ft)
T
2500.0 m
( 8202.10 ft)
987.5 m
( 3239.83 ft)
500.0 m
( 1640.42 ft)
250.0 m
( 820.21 ft)
*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Intelligence
Intelligence Notes Only video metadata, perimeter protection and face detection cannot be enabled at a time.
IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human and vehicle alarm classification; linkage tracking. Offers Perimeter Protection Large-Scale AI Models to extend the target detection range and reduce the rate of false alarm. Supports self-learning, it filters out false alarms.
Smart Object Detection Smart Abandoned Object and Smart Missing Object. By implementing Object Detection Large-Scale AI Models, it allows the camera to identify a wider range of objects.
SMD SMD 4.0
AcuPick Uses deep learning algorithms and works with backend devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets
Face Detection Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot)
PPE Detection Detects 6 helmet colors: Red, orange, yellow, blue, white, and black. An alarm will be triggered when a person is not wearing a helmet or when the color of the helmet that they are wearing does not match the configured color. It also supports compliance detection for work uniforms. Up to 5 work uniform sample libraries can be uploaded, which together can contain up to 1,000 images (the images must b
