PTZ85448-HNF-PA-FL
4MP 48x Starlight Laser AI Network Positioning System
Key Points

High-Quality Imaging with 4MP Resolution

48× Optical Zoom Provide Close Up Views Over Expansive Areas

1/1.8″ CMOS Sensor Ensures Premium Images

Expansive Night View With up to 1000 m IR Distance for 24/7 Monitoring

Face Recognition: Supports Face Information Collection, Property Expression Fetching, Face Database Management and Comparison

Video Metadata: Multi-Target Detection and Analysis with Real-Time Tracking

Real-Time Communication via Built-In Two-Way Audio

IP67 for Protection Against Harsh Environments

Sales Enquiry
Datasheet
Specifications

Camera

Image Sensor

1/1.8″ CMOS

Pixel

4 MP

Max. Resolution

2560 (H) × 1440 (V)

ROM

8 GB

RAM

2 GB

Electronic Shutter Speed

1/1 s–1/30,000 s

Scanning System

Progressive

Min. Illumination

Color: 0.001 lux@F1.4
B/W: 0.0001 lux@F1.4
0 lux (laser on)

Illumination Distance

1,000 m (3,280.84 ft)

Illuminator On/Off Control

Zoom Prio; Manual; Off

Illuminator Number

1 (laser)

Wiper

Yes

Lens

Focal Length

6.25 mm–300 mm

Max. Aperture

F1.4–F4.5

Field of View

H: 62.4°–1.7°; V: 36.6°–1.0°; D: 69.8°–2.0°

Optical Zoom

48×

Focus Control

Auto; semi-auto; manual

Close Focus Distance

0.5 m–2 m (1.64–6.56 ft)

Iris Control

Auto; manual

DORI Distance

Detect

Observe

Recognize

Identify

6,000 m (19,685.04 ft)

2,381 m (7,811.68 ft)

1,200 m (3,937.01 ft)

600 m (1,968.50 ft)

DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless
Tilt: –45° to +90°

Manual Control Speed

Pan: 0.1°/s–160°/s
Tilt: 0.1°/s–60°/s

Preset Speed

Pan: 160°/s; Tilt: 60°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Preset; Pattern; Tour; Scan

PTZ Protocol

DH-SD

Pelco-P/D (auto recogniton)

Intelligence

Video Metadata

Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction.

IVS (Perimeter Protection)

Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification.

Face Recognition

Yes

Video

Video Compression

H.265; H.264M; H.264H; MJPEG; Smart H.265; Smart H.264

Streaming Capability

3 streams

Resolution

4M (2560 × 1440); 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Video Frame Rate

Main stream: 4M/1080p/960p/720p (1–50/60 fps)
Sub stream 1: D1/VGA/CIF (1–25/30 fps)
Sub stream 2: 1080p/960p/720p (1–25/30 fps)

Bit Rate Control

CBR; VBR

Video Bit Rate

H.264: 2816–13056 kbps
H.265: 1024–7936 kbps

Day/Night

Auto (ICR); Color; B/W

BLC

Yes

WDR

140 dB

HLC

Yes

White Balance

Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Defog

Optical

Image Stabilization

Electronic Image Stabilization (EIS)

Digital Zoom

16×

Image Rotation

180°

Privacy Masking

U
