IPC-HFW3249T-ZAS-IL
2MP Smart Dual Light Vari-focal Bullet WizSense Network Camera
Key Points
High-Quality Imaging with 2 MP Resolution
Motorized Varifocal Lens for Easy Installation and Monitoring
Smart Dual Light: Built-in IR and LED Lights with 3 Illumination Modes Supported
Enhanced Deep Learning-Based Human and Vehicle Classification
Xinghan Vision Models: Comprehensive Enhancement of Target Detection, Imaging
AcuPick Enables Fast and Precise Human&Vehicle Search
Built-in Mic for Real-Time Audio Security
IP67 for Protection Against Harsh Environments
Sales Enquiry
Datasheet
Specifications
Camera
Image Sensor
1/2.9″ CMOS
Max. Resolution
1920 (H) × 1080 (V)
ROM
256 MB
RAM
1 GB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.002 lux@F1.4 (Color, 30 IRE)
0.0002 lux@F1.4 (B/W, 30 IRE)
0 lux (Illuminator on)”
S/N Ratio
>56 dB
Illumination Distance
Up to 60 m (196.85 ft) (IR)
Up to 60 m (196.85 ft) (Warm light)
Illuminator On/Off Control
Auto; Manual
Illuminator Number
4 (Multi-core (IR + warm) light)
Angle Adjustment
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
Lens
Lens Type
Motorized vari-focal
Lens Mount
φ14
Focal Length
2.7 mm-13.5 mm
Max. Aperture
F1.4
Field of View
H: 104°–29°; V: 54°–16°; D: 125°–34°
Iris Control
Fixed
Close Focus Distance
0.1 m (0.33 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
45.7 m
(149.93 ft)
18.3 m
(60.04 ft)
9.1 m
(29.86 ft)
4.6 m
(15.09 ft)
T
150.0 m
(492.13 ft)
60.0 m
(196.85 ft)
30.0 m
(98.43 ft)
15.0 m
(49.21 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Intelligence
IVS (Perimeter Protection)
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), stay detection, loitering detection.
Face Detection(Full Image)
Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.
SMD
SMD 4.0
AcuPick
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
AI SSA
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
AI Coding
AI H.265; AI H.264
*includes SmartCodec Technology,Smart H.264+ /H.265+
Video Frame Rate
Main stream: 1920 × 1080@(1 fps–25/30 fps)
Sub stream: 1920 × 1080@(1 fps–25/30 fps)
Third stream: 1920 × 1080@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability
3 streams
Resolution
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 7
